submersible water pump,small submersible pump,12v submersible pump
Voltage：12V / 24V
Flow Rate：3000/3700/4700 GPH
Outlet Dia：1.5" (40mm) 2"(52mm)
Application Scenarios：Drainage of accumulated water
SEAFLO 12V Electric Marine Submersible non-automatic 3000GPH,3700GPH,4700GPH bilge pumps offer water evacuation activated by a panel or float switch. Include Anti-Airlock protection and exclusive moisture tight seals, marine grade blocked wiring. Pumps offer a choice of straight or 90 degree ports to suit your installation. Our larger impeller design and more robust motor allow us to outperform our competitors. New innovative split quick-connect joint design removes and installs in seconds! Change pump never been so easy. No need to disconnect base or plumbing when replacing pump, which can meet the needs of most users. Just replace the motor that is all.
FEATURES & BENEFITS
MORE FEATURES & BENEFITS
• CE, RoHS, ISO 8846, ISO 8849 standards
• Traditional operation by switch or float switch
• Entirely Submersible
• Run dry capable for workloads
• High efficiency, low amp motor, quiet operation
• Stainless steel shaft
• Snap-off strainer base for easy maintenance
• Pump and switch are stand alone products
• Sealed efficient, long life motors
• Anti-Airlock protection
• Exclusive moisture tight seals
• Marine grade blocked wiring
• 2 Year Warranty
STANDARD PUMP CONFIGURATIONS
Model | Flow rate | Volts | Current | Head |
SFBP1-G3000-13A | 3000GPH | 12V | 12A | 5.5m/18.04' |
SFBP2-G3000-13A | 3000GPH | 24V | 6A | 5.5m/18.04' |
SFBP1-G3700-13A | 3700GPH | 12V | 14A | 6.0m/19.69' |
SFBP2-G3700-13A | 3700GPH | 24V | 7A | 6.0m/19.69' |
SFBP1-G4700-13A | 4700GPH | 12V | 16A | 6.5m/21.33' |
SFBP2-G4700-13A | 4700GPH | 24V | 8A | 6.5m/21.33' |
SHIPPING INFORMATION
Unit Weight | |
Selling Unit Size (L x W x H) | |
Selling Unit Weight | |
Master Carton Size (L x W x H) | ( 20.47" x 14.17" x 9.05") 52 x 36 x 23 cm |
Master Carton Qty | 8 pcs |
Master Carton Weight | 46.30 lbs (21 kg) |
Master Carton Volume | 0.043 m³ |
